Product category： Epoxy potting resin potting adhesive
-
-
Application： Electronic products
-
-
Product feature 1： This resin has high thermal conductivity.
-
-
Product feature 2： The cured material is soft, with excellent toughness and electrical characteristics.
-
-
Product feature 3： The flame retardant of the finished product reaches the UL94V_0 (6.4mm) certification standard
|
Product performance;
N8036A/B
|
test item
|
unit
|
temperature
|
typical values
|
|
A liquid
|
B liquid
|
|
Each properties
|
appearance
|
——
|
25℃
|
black paste
|
light yellow transparent
|
|
ingredient
|
——
|
——
|
epoxy resin
|
Modified amine
|
|
specific gravity
|
——
|
25℃
|
2.60
|
0.98
|
|
viscosity
|
Pa·s
|
25℃
|
185
|
0.06
|
|
mixture ratio by weight
|
——
|
——
|
100
|
10
|
|
initial viscosity
|
Pa·s
|
25℃
|
9
|
|
Gelation time
|
min
|
80℃
|
120min
|
|
curing condition
|
——
|
——
|
100℃/2h+120℃/2h
|
|
cured properties
|
the cured color
|
——
|
25℃
|
black
|
|
hardness(Shore A)
|
——
|
room temperature
|
45～55
|
|
Thermal conductivity
|
w/mk
|
25℃
|
≥1.9
|
|
Coefficient of linear expansion
|
K
|
——
|
11×10-5
|
|
Volume resistivity(DC500V)
|
MΩ·m
|
25℃
|
1.5×104
|
|
Insulation strength
|
kV/mm
|
25℃
|
>15
|
|
Usable temperature range
|
℃
|
——
|
-40～130
|
Remark; More technical parameter data, production process recommendation, MSDS and other information, please ask for the technical department of Wu Co., LTD.tech@wuxinozawa.com
